Description
DELL UltraSharp U3425WE. Display diagonal: 86.7 cm (34.1"), Display resolution: 3440 x 1440 pixels, HD type: Wide Quad HD, Display technology: LCD, Response time: 8 ms, Native aspect ratio: 21:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in speaker(s). Built-in USB hub, USB hub version: 3.2 Gen 2 (3.1 Gen 2). VESA mounting, Height adjustment. Product colour: Black, Silver
Key Features
- 86.7 cm (34.1") Black, Silver
- Height adjustment 15 cm Built-in speaker(s)
- USB upstream port type: USB Type-C HDMI HDMI version: 2.1 DisplayPorts quantity: 1 DisplayPort version: 1.4
- Screen shape: Curved
- Maximum refresh rate: 120 Hz Response time: 8 ms
- 3440 x 1440 pixels Wide Quad HD Panel type: IPS
- Energy efficiency class (SDR): F ENERGY STAR, TCO RoHS
Specifications
| Dimensions Weight | |
|---|---|
| Weight (without stand) | 10370 g |
| Width (with stand) | 813.46 mm |
| Display Screen | |
| Screen Color Gamut | DCI-P3 |
| Screen Diagonal (cm) | 867 mm |
| Screen HD Type | Widequadhd |
| Screen HDR Support | N |
| Screen Horizontal Scan Range (kHz) | 25 - 185 |
| Screen LED Backlight Type | LED |
| Screen Native Aspect Ratio | 21 9 |
| Screen Panel Type | IPS |
| Screen Pixel Density (PPI) | 110 |
| Screen Pixel Pitch | 0.2325 x 0.2325 |
| Screen Response Time (ms) | 8 ms |
| Screen Shape | Curvedscreen |
| Screen Vertical Scan Range | 48 - 120 |
| Swiveling Support | Yes |
| Tilt Adjustment Support | Yes |
| VESA Mount Support | Yes |
| Audio | |
| Built-in speaker(s) | Yes |
| Number of speakers | 2 |
| Battery | |
| Product colour | Black, Silver |
| Camera | |
| Built-in camera | No |
| HD type | Wide Quad HD |
| High Dynamic Range (HDR) supported | No |
| On Screen Display (OSD) | Yes |
| Supported graphics resolutions | 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1600 x 1200, 1920 x 1080 (HD 1080), 2560 x 1440, 3440 x 1440, 640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA) |
| Tilt angle range | -5 - 21 |
| Carbon footprint | |
| Total carbon footprint (kg of CO2e) | 361 |
| Certificates | |
| Compliance certificates | RoHS |
| Doesn't contain | PVC/BFR |
| Computer system | |
| VESA mounting | Yes |
| Control unit | |
| Remote control included | No |
| Design | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Cable management | Yes |
| Display diagonal | 34.14 |
| Display resolution | 3440 x 1440 |
| Display technology | LCD |
| Ethernet LAN (RJ-45) ports | 1 |
| Height adjustment | Y |
| LED backlight | Yes |
| LED indicators | Yes |
| Market positioning | Business |
| Operating relative humidity (H-H) | 10 - 80 |
| Operating temperature (T-T) | 0 - 40 |
| Panel mounting interface | 100 x 100 mm |
| Storage relative humidity (H-H) | 5 - 90 |
| Storage temperature (T-T) | -20 - 60 |
| Swivel angle range | -30 - 30 |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Touchscreen | No |
| Wall mountable | Yes |
| Display | |
| Anti-glare screen | Yes |
| Colour gamut standard | DCI-P3 |
| Display brightness (typical) | 300 |
| Low Blue Light technology | Yes |
| Maximum refresh rate | 120 |
| Native aspect ratio | 21:9 |
| Panel type | IPS |
| Pixel density | 110 |
| Response time | 8 |
| sRGB coverage (typical) | 100 |
| Vertical scan range | 48 - 120 |
| Docking station | |
| Built-in USB hub | Yes |
| HDMI ports quantity | 1 |
| HDMI version | 2.1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 90 |
| Ergonomics | |
| Adjustable height (max) | 150 |
| Features | |
| AC input voltage | 100 - 240 |
| Cables included | AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-C |
| Carbon emissions, end-of-life (kg of CO2e) | 29.6 |
| Carbon emissions, energy usage (kg of CO2e) | 154.15 |
| Carbon emissions, logistics (kg of CO2e) | 28.16 |
| Carbon emissions, manufacturing (kg of CO2e) | 149.09 |
| Depth (with stand) | 240.43 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI | Yes |
| Headphone out | Yes |
| Package weight | 15050 |
| Power supply type | Internal |
| Stylus included | No |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Wi-Fi | No |
| Graphics | |
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
| Performance | |
| Flicker-free technology | Yes |
| Weight & dimensions | |
| Height (without stand) | 359.15 |
| Weight (without stand) | 10370 |
| Width (without stand) | 813.46 |
Extra Information
Brand:
DELL
Carbon emissions, manufacturing (kg of CO2e):
149.09
Carbon emissions, logistics (kg of CO2e):
28.16
Carbon emissions, energy usage (kg of CO2e):
154.15
Carbon emissions, end-of-life (kg of CO2e):
29.6
PAIA version:
GaBi version 1, 2024
LED indicators:
Yes
Cable lock slot:
Yes
Cable lock slot type:
Kensington
Feet colour:
Silver
Market positioning:
Business
Front bezel colour:
Black
Detachable stand:
Yes
Touchscreen:
No
Display diagonal:
34.14
Display resolution:
3440 x 1440
Native aspect ratio:
21:9
HD type:
Wide Quad HD
Panel type:
IPS
Screen Shape:
Curvedscreen
Contrast ratio (typical):
2000:1
Maximum refresh rate:
120
Display number of colours:
1.07 billion colours
Display brightness (typical):
300
Supported graphics resolutions:
1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1600 x 1200, 1920 x 1080 (HD 1080), 2560 x 1440, 3440 x 1440, 640 x 480 (VGA), 720 x 480, 800 x 600 (SVGA)
Viewing angle, horizontal:
178°
Viewing angle, vertical:
178°
Viewable size, horizontal:
80 cm
Viewable size, vertical:
33.5 cm
Display technology:
LCD
Anti-glare screen:
Yes
Pixel pitch:
0.2325 x 0.2325 mm
Colour gamut:
98%
Backlight type:
LED
Response time (fast):
5 ms
Pixel density:
110
Colour gamut standard:
DCI-P3
Screen curvature rating:
1900R
Horizontal scan range:
25 - 185 kHz
Vertical scan range:
48 - 120
Viewable size diagonal:
86.7 cm
High Dynamic Range (HDR) supported:
No
Surface hardness:
3H
sRGB coverage (typical):
100
Height adjustment:
Y
Tilt adjustment:
Yes
Tilt angle range:
-5 - 21
Swivelling:
Yes
Swivel angle range:
-30 - 30
VESA mounting:
Yes
Adjustable height (max):
150
Pivot:
No
Cable management:
Yes
On Screen Display (OSD):
Yes
Product colour:
Black, Silver
Wall mountable:
Yes
Plug and Play:
Yes
Power supply type:
Internal
Panel mounting interface:
100 x 100 mm
Built-in speaker(s):
Yes
Built-in camera:
No
RMS rated power:
10 W
Wi-Fi:
No
Operating temperature (T-T):
0 - 40
Storage temperature (T-T):
-20 - 60
Operating relative humidity (H-H):
10 - 80
Storage relative humidity (H-H):
5 - 90
Operating altitude:
0 - 5000 m
Non-operating altitude:
5000 - 12192 m
Number of speakers:
2
Heavy metals free:
Hg (mercury)
Cables included:
AC, DisplayPort, HDMI, Thunderbolt, USB Type-A to USB Type-C
Quick start guide:
Yes
Stand included:
Yes
Power adapter included:
Yes
Remote control included:
No
Stylus included:
No
Package weight:
15050
Supported video modes:
480p, 576p, 720p, 1080i, 1080p
NVIDIA G-SYNC:
No
AMD FreeSync:
No
Flicker-free technology:
Yes
Low Blue Light technology:
Yes
Ethernet LAN (RJ-45) ports:
1
HDMI ports quantity:
1
Headphone outputs:
1.0
DisplayPorts quantity:
1
HDMI version:
2.1
Built-in USB hub:
Yes
HDMI:
Yes
Headphone out:
Yes
USB hub version:
3.2 Gen 2 (3.1 Gen 2)
USB Type-A downstream ports quantity:
5.0
DisplayPort version:
1.4
HDCP:
Yes
Thunderbolt 4 ports quantity:
2.0
USB Power Delivery up to:
90
USB Type-C DisplayPort Alternate Mode:
Yes
Number of USB Type-C upstream ports quantity:
2.0
USB upstream port type:
USB Type-C
USB Type-C downstream ports quantity:
3.0
HDCP version:
1.4/2.2
AC input voltage:
100 - 240
AC input frequency:
50/60 Hz
Power consumption (max):
250 W
Power consumption (typical):
31.5 W
Input current:
3.2 A
USB Power Delivery (USB PD):
Yes
Energy efficiency class (SDR):
F
Energy consumption (SDR) per 1000 hours:
32 kWh
Power consumption (standby):
0.5 W
Power consumption (off):
0.3 W
Energy efficiency scale:
A to G
European Product Registry for Energy Labelling (EPREL) code:
1777749.0
Energy efficiency class (HDR):
Not available
Response time:
8
Sustainability certificates:
ENERGY STAR, TCO
Doesn't contain:
PVC/BFR
Total carbon footprint (kg of CO2e):
361
Compliance certificates:
RoHS
Weight (with stand):
7.78 kg
Width (with stand):
813.46 mm
Depth (with stand):
240.43
Height (with stand):
542.8 mm
Width (without stand):
813.46
Depth (without stand):
105.1 mm
Height (without stand):
359.15
Weight (without stand):
10370 g
Bezel width (side):
9.78 mm
Bezel width (top):
1.04 cm
Bezel width (bottom):
1.39 cm
Sustainability compliance:
Yes
Screen Color Gamut:
DCI-P3
Screen Diagonal (cm):
867 mm
Screen HD Type:
Widequadhd
Screen HDR Support:
N
Screen Horizontal Scan Range (kHz):
25 - 185
Screen LED Backlight Type:
LED
Screen Native Aspect Ratio:
21 9
Screen Panel Type:
IPS
Screen Pixel Density (PPI):
110
Screen Pixel Pitch:
0.2325 x 0.2325
Screen Response Time (ms):
8 ms
Screen Vertical Scan Range:
48 - 120
Swiveling Support:
Yes
Tilt Adjustment Support:
Yes
VESA Mount Support:
Yes
Weight (without stand):
10370
Download | Brochure DELL DELL-U3425WE:
https://icecat.biz/rest/product-pdf
Download | Dell UltraSharp 34 Curved Thunderbolt Hub Monitor - U3425WE User’s Guide:
https://objects.icecat.biz/objects/mmo_119532546_1709646059_1143_2831351.pdf
Download | Firmware Update Instructions for MAC:
https://objects.icecat.biz/objects/mmo_119532546_1709645236_9034_475975.pdf
Download | Dell UltraSharp 34 Curved Thunderbolt Hub Monitor - U3425WE Quick Start Guide:
https://objects.icecat.biz/objects/mmo_119532546_1709645227_4281_4076173.pdf
Download | Dell UltraSharp 34 Curved Thunderbolt Hub Monitor - U3425WE Outline Dimensions:
https://objects.icecat.biz/objects/mmo_119532546_1709645214_8734_52728.pdf
Download | EU Energy Label:
https://objects.icecat.biz/objects/mmo_119532546_1709563485_9941_22225.pdf
Download | EU Declaration of Conformity:
https://objects.icecat.biz/objects/mmo_119532546_1739981888_2143_61.pdf
Download | Dell Display Manager 2.3 for Windows User’s Guide:
https://objects.icecat.biz/objects/mmo_119532546_1709645359_3017_2097680.pdf
Download | Firmware Update Instructions for Windows:
https://objects.icecat.biz/objects/mmo_119532546_1709645246_1198_421103.pdf
Download | Dell Display and Peripheral Manager on Mac User's Guide:
https://objects.icecat.biz/objects/mmo_119532546_1709645395_8748_1777554.pdf
Download | Dell UltraSharp 34 Curved Thunderbolt Hub Monitor - U3425WE Statement of Volatility:
https://objects.icecat.biz/objects/mmo_119532546_1709645267_8292_1341564.pdf
Download | EU Product Fiche:
https://objects.icecat.biz/objects/mmo_119532546_1709563511_3778_13791.pdf
Download | User manual:
https://objects.icecat.biz/objects/mmo_119532546_1709645605_8657_3642816.pdf
Download | Firmware Update Instructions for Ubuntu:
https://objects.icecat.biz/objects/mmo_119532546_1709645261_7037_1577004.pdf
Download | Dell UltraSharp 34 Curved Thunderbolt Hub Monitor - U3425WE Teardown Instructions:
https://objects.icecat.biz/objects/mmo_119532546_1709645353_1939_3964522.pdf
ERP Category:
DELL_RETAIL
Icecat Category:
Computer Monitors
LED backlight:
Yes
