Description
Optimization in One-Click Mode, Achieving Better Wi-Fi Experience
Wi-Fi Intelligent Optimization (WIO) technology allows you to optimize a wireless network in one-click mode.
Easy Wi-Fi Network Construction Within 3 Minutes
With self-organizing network (SON) technology, a Wi-Fi network can be easily built through Ruijie Reyee App.
Cloud, Make Your Business Easy
Self-organized Network (SON) Centralized Network Management Scenario-based Configuration
Cloud Portal Authentication Remote Monitoring and Maintenance
Wi-Fi Intelligent Optimization (WIO) technology allows you to optimize a wireless network in one-click mode.
Easy Wi-Fi Network Construction Within 3 Minutes
With self-organizing network (SON) technology, a Wi-Fi network can be easily built through Ruijie Reyee App.
Cloud, Make Your Business Easy
Self-organized Network (SON) Centralized Network Management Scenario-based Configuration
Cloud Portal Authentication Remote Monitoring and Maintenance
Key Features
- 2.4 GHz 400 Mbit/s
- 5 GHz 866.7 Mbit/s
- Maximum data transfer rate: 1267 Mbit/s
- IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
- SSID, WPA-PSK, WPA-TKIP, WPA2-AES
- Power over Ethernet (PoE)
- Internal
Specifications
| Dimensions Weight | |
|---|---|
| Width | 86 mm |
| Height | 29 mm |
| Depth | 86 mm |
| Weight | 250 g |
| Antenna | |
| Antenna type | Internal |
| Battery | |
| Product colour | White |
| Call management | |
| Web-based management | Yes |
| Data transmission | |
| Maximum data transfer rate | 1267 |
| Design | |
| Ethernet LAN (RJ-45) ports | 2 |
| Operating relative humidity (H-H) | 5 - 95 |
| Storage relative humidity (H-H) | 5 - 95 |
| Ethernet LAN features | |
| Ethernet LAN data rates | 10, 100 |
| Features | |
| 5 GHz | Yes |
| 6 GHz | No |
| Depth | 86 |
| Height | 29 |
| Maximum data transfer rate (5 GHz) | 866 |
| MIMO | Yes |
| MIMO type | Multi User MIMO |
| Number of users | 110 |
| Power over Ethernet (PoE) | Yes |
| Security algorithms | Ssid, Wpa2 Aes, WPA-PSK, WPA-TKIP |
| Network | |
| Networking standards | IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n |
| Security | |
| Number of SSID supported | 8 |
Extra Information
Brand:
Ruijie Networks
Width:
86 mm
Height:
29 mm
Depth:
86 mm
Weight:
250 g
Antenna type:
Internal
Product colour:
White
Web-based management:
Yes
Maximum data transfer rate:
1267
Ethernet LAN (RJ-45) ports:
2
Operating relative humidity (H-H):
5 - 95
Storage relative humidity (H-H):
5 - 95
Ethernet LAN data rates:
10, 100
5 GHz:
Yes
6 GHz:
No
Depth:
86
Height:
29
Maximum data transfer rate (5 GHz):
866
MIMO:
Yes
MIMO type:
Multi User MIMO
Number of users:
110
Power over Ethernet (PoE):
Yes
Security algorithms:
Ssid, Wpa2 Aes, WPA-PSK, WPA-TKIP
Networking standards:
IEEE 802.11ac, IEEE 802.11b, IEEE 802.11g, IEEE 802.11n
Number of SSID supported:
8
