Description
Better Multi-User Experience in High-Density Scenarios
Enjoy better performance with MU-MIMO technology under 802.11ac Wave2.
One Click to Optimize, Get Better Wi-Fi Experience
The WIO (Wi-Fi Intelligent Optimization) technology allows you to optimize wireless network by one click.
Layer 3 Roaming, Smooth Transition
Roam smoothly between Layer 3 networks with non-interruption.
Easily Set Up Your Wi-Fi Network in 3 Minutes
With SON (Self-organizing Network) technology, easily set up a whole Wi-Fi network by Ruijie Cloud APP.
Enjoy better performance with MU-MIMO technology under 802.11ac Wave2.
One Click to Optimize, Get Better Wi-Fi Experience
The WIO (Wi-Fi Intelligent Optimization) technology allows you to optimize wireless network by one click.
Layer 3 Roaming, Smooth Transition
Roam smoothly between Layer 3 networks with non-interruption.
Easily Set Up Your Wi-Fi Network in 3 Minutes
With SON (Self-organizing Network) technology, easily set up a whole Wi-Fi network by Ruijie Cloud APP.
Key Features
- 2.4 GHz
- 5 GHz
- Maximum data transfer rate: 1267 Mbit/s
- IEEE 802.3af, IEEE 802.3at
- Power over Ethernet (PoE)
- Internal Integrated antenna
Specifications
| Dimensions Weight | |
|---|---|
| Width | 194 mm |
| Height | 35 mm |
| Depth | 194 mm |
| Weight | 450 g |
| Antenna | |
| Antenna features | Integrated antenna |
| Antenna type | Internal |
| Battery | |
| Product colour | White |
| Data transmission | |
| Maximum data transfer rate | 1267 |
| Design | |
| Ethernet LAN (RJ-45) ports | 2 |
| LED indicators | Power |
| Quantity per pack | 1 |
| Ethernet LAN features | |
| Cabling technology | 10 100base T X |
| Ethernet LAN data rates | 10, 100, 1000 Mbit/s |
| Features | |
| 5 GHz | Yes |
| Depth | 194 |
| Frequency band | 2.4 - 5 |
| Height | 35 |
| MIMO | Yes |
| Modulation | 1024-QAM, 16-QAM, 256-QAM, 64-QAM, BPSK, CCK, Dbpsk, Dqpsk, Dsss, QPSK |
| Power over Ethernet (PoE) | Yes |
| VLAN support | Yes |
| Network | |
| Networking standards | IEEE 802.3af, IEEE 802.3at |
Extra Information
Brand:
Ruijie Networks
Antenna features:
Integrated antenna
Product colour:
White
LED indicators:
Power
Certification:
CE, ROHS
2.4 GHz:
Yes
5 GHz:
Yes
VLAN support:
Yes
Throughput data rate:
1267 Mbit/s
Number of WLAN connections (max):
110.0
Antenna type:
Internal
Networking standards:
IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates:
10, 100, 1000 Mbit/s
Cabling technology:
10 100base T X
MIMO:
Yes
Modulation:
1024-QAM, 16-QAM, 256-QAM, 64-QAM, BPSK, CCK, Dbpsk, Dqpsk, Dsss, QPSK
Operating temperature (T-T):
0 - 40 °C
Quantity per pack:
1
Maximum data transfer rate:
1267
Frequency band:
2.4 - 5
Ethernet LAN (RJ-45) ports:
2
Power over Ethernet (PoE):
Yes
Blacklist:
Yes
Whitelist:
Yes
Width:
194 mm
Height:
35 mm
Weight:
450 g
Depth:
194 mm
Depth:
194
Height:
35
ERP Category:
RUIJIE_NETWORKS
