Description
Big Performance in a Compact PC
- High-performing business desktop that fits anywhere, even horizontally positioned
- Optimized workloads with up to Intel® Core™ performance
- Fast data processing with dual-channel memory
- Enhanced privacy & enterprise-grade security
- High-performing business desktop that fits anywhere, even horizontally positioned
- Optimized workloads with up to Intel® Core™ performance
- Fast data processing with dual-channel memory
- Enhanced privacy & enterprise-grade security
Extra Information
Brand:
Lenovo
Antenna type:
2x2
Built-in speaker(s):
Yes
Audio chip:
Realtek ALC233VB
Audio system:
High Definition Audio
Compliance certificates:
RoHS
Product colour:
Black
Colour name:
Black
Chassis type:
Mini PC
Display included:
No
Ethernet LAN data rates:
100,1000 Mbit/s
SSD capacity:
512 GB
SSD form factor:
M.2
Internal memory:
16 GB
Internal memory type:
DDR5-SDRAM
ECC:
No
Memory clock speed:
4800 MHz
NVMe:
Yes
Cabling technology:
10/100/1000Base-T(X)
On-board graphics card:
Yes
Discrete graphics card:
No
Discrete graphics card model:
Not available
On-board graphics card model:
Intel UHD Graphics 730
On-board GPU manufacturer:
Intel
On-board graphics card family:
Intel® UHD Graphics
Bluetooth version:
5.3
Memory layout (slots x size):
1 x 16 GB
Memory slots:
2x DIMM
Non-ECC:
Yes
Maximum internal memory:
64 GB
Memory channels:
Dual-channel
Mouse included:
Yes
Ethernet LAN:
Yes
Top Wi-Fi standard:
Wi-Fi 6E (802.11ax)
Wi-Fi standards:
802.11a, 802.11b, 802.11g, Wi-Fi 4 (802.11n), Wi-Fi 5 (802.11ac), Wi-Fi 6 (802.11ax), Wi-Fi 6E (802.11ax)
WLAN controller model:
Intel Wi-Fi 6E AX211
WLAN controller manufacturer:
Intel
Wi-Fi:
Yes
Operating temperature (T-T):
5 - 35 °C
Operating relative humidity (H-H):
20 - 80%
Storage temperature (T-T):
-40 - 60 °C
Storage relative humidity (H-H):
10 - 90%
Operating altitude:
0 - 3048 m
Non-operating altitude:
0 - 12192 m
Number of speakers:
1.0
Keyboard included:
Yes
Keyboard connectivity:
Wired
Mouse connectivity:
Wired
Package width:
490 mm
Package depth:
128 mm
Package height:
250 mm
Package weight:
3.2 kg
Product type:
Mini PC
Certification:
ENERGY STAR,TCO,EPEAT Silver,RoHS
Card reader integrated:
No
Cable lock slot:
Yes
Cable lock slot type:
Kensington
VESA mounting:
Yes
Motherboard chipset:
Intel Q670
USB 3.2 Gen 1 (3.1 Gen 1) Type-A ports quantity:
1.0
HDMI ports quantity:
1.0
DisplayPorts quantity:
1.0
Ethernet LAN (RJ-45) ports:
1.0
USB 2.0 ports quantity:
1.0
Bluetooth:
Yes
USB 3.2 Gen 1 (3.1 Gen 1) Type-C ports quantity:
1.0
HDMI version:
2.1
Combo headphone/mic port:
Yes
DisplayPort version:
1.4a
USB 3.2 Gen 2 (3.1 Gen 2) Type-A ports quantity:
4.0
Number of rear USB ports:
4.0
Number of front USB ports:
3.0
Number of front audio ports:
1.0
M.2 card slot (wireless):
1.0
M.2 card slot (storage):
2.0
Power supply:
90 W
Power supply input voltage:
100 - 240 V
Power supply input frequency:
50/60 Hz
Processor family:
Intel® Core™ i5
Processor manufacturer:
Intel
Processor model:
i5-14400T
Processor generation:
Intel® Core™ i5 (14th gen)
Processor cores:
10.0
Processor threads:
16.0
Processor boost frequency:
4.5 GHz
Performance cores:
6.0
Efficient cores:
4.0
Performance-core Max Turbo Frequency:
4.5 GHz
Efficient-core Max Turbo Frequency:
3.2 GHz
Performance-core base frequency:
1.5 GHz
Efficient-core base frequency:
1.1 GHz
Processor cache:
20 MB
Processor cache type:
Smart Cache
Processor base power:
35 W
Maximum turbo power:
82 W
Number of processors installed:
1.0
Password protection:
Yes
Password protection type:
BIOS, HDD, Power on, Supervisor
Trusted Platform Module (TPM):
Yes
Trusted Platform Module (TPM) version:
2.0
Operating system installed:
Windows 11 Pro
Operating system architecture:
64-bit
Operating system language:
English
Total storage capacity:
512 GB
Storage media:
SSD
Optical drive type:
No
Total SSDs capacity:
512 GB
Number of SSDs installed:
1.0
SSD interface:
PCI Express 4.0
M.2 SSD size:
2280 (22 x 80 mm)
Number of storage drives installed:
1.0
Sustainability certificates:
ENERGY STAR, EPEAT Silver, ErP, GREENGUARD, TCO
Width:
179 mm
Depth:
182.9 mm
Height:
36.5 mm
Weight:
1.25 kg
Volume:
1 L
