Description
HPE Networking Instant On Switch 1830 series provides an easy to use and affordable wired solution for networks supporting IT, mobile, and cloud applications. This affordable and easy-to-deploy smart-managed switch series is ideal for small businesses looking for cost-effective wired infrastructure to keep up with evolving network demands. These entry-level, smart-managed switches offer Layer 2 switching capabilities, Gigabit connectivity, along with flexible management modes - all at an affordable price point. With a flexible management dashboard, Power over Ethernet (PoE) options, and energy-efficient features, these switches deliver a solid business network for SMBs with limited budgets.
What is new supporting point:
Smart-managed Layer 2 Ethernet switch series ready to deploy in 8, 24-, and 48-port for non-PoE and PoE models.
Compact and fan-less 8-port PoE/ non-PoE models and 24-port non-PoE model for acoustically sensitive environments.
Option to manage your switches through local web GUI.
Two and four dedicated 1G SFP fiber ports on 24- and 48-port models respectively to eliminate traffic bottlenecks across your network.
HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
Cost-effective PoE support: With half of the ports capable of supporting PoE, these switches are ideal for the most cost-efficient environments.
What is new supporting point:
Smart-managed Layer 2 Ethernet switch series ready to deploy in 8, 24-, and 48-port for non-PoE and PoE models.
Compact and fan-less 8-port PoE/ non-PoE models and 24-port non-PoE model for acoustically sensitive environments.
Option to manage your switches through local web GUI.
Two and four dedicated 1G SFP fiber ports on 24- and 48-port models respectively to eliminate traffic bottlenecks across your network.
HPE Networking Instant On mobile app and/or cloud-based web portal for easy network management onsite or remotely.
Cost-effective PoE support: With half of the ports capable of supporting PoE, these switches are ideal for the most cost-efficient environments.
Key Features
- Managed L2 Web-based management
- Quality of Service (QoS) support
- Basic switching RJ-45 Ethernet ports quantity: 48
- MAC address table: 16000 entries Switching capacity: 104 Gbit/s
- 1U Rack mounting
- AC Power supply included
Specifications
| Dimensions Weight | |
|---|---|
| Width | 253 mm |
| Weight | 3540 g |
| Call management | |
| Web-based management | Yes |
| Camera | |
| Built-in processor | Yes |
| Processor frequency | 800 |
| Computer system | |
| Internal memory | 512 |
| Processor model | Armcortex A9 |
| Data transmission | |
| Latency (1 Gbps) | 2 |
| Latency (10-100 Mbps) | 5 |
| Switching capacity | 104 |
| Design | |
| Form factor | 1U |
| Operating relative humidity (H-H) | 15 - 95 |
| Rack mounting | Yes |
| Storage relative humidity (H-H) | 15 - 95 |
| Features | |
| AC input voltage | 100 - 240 |
| Depth | 443 |
| Flash memory | 256 |
| Harmonized System (HS) code | 85176990 |
| Height | 43 |
| I/O ports | 48 RJ-45 10/100/1000 ports, 4 SFP 1GbE ports |
| Power over Ethernet (PoE) | No |
| Quality of Service (QoS) support | Yes |
| SFP+ module slots quantity | 4 |
| Switch layer | L2 |
| Switch type | Managed |
| VLAN support | Yes |
| Network | |
| 10G support | No |
| Networking standards | Ieee802 1ab, Ieee802 1d, Ieee802 1p, Ieee802 1q, Ieee802 1w, Ieee802 3, Ieee802 3ab, Ieee802 3ac, Ieee802 3ad, Ieee802 3az, Ieee802 3u, Ieee802 3x, Ieee802 3z |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 48 |
| Basic switching RJ-45 Ethernet ports type | Gigabitethernet 10 100 1000 |
| Security | |
| DHCP features | Dhcpclient |
| SSH/SSL support | Yes |
