Description
HPE Aruba Networking 500 Series Campus Access Points deliver cost-effective Wi-Fi 6 coverage for indoor environments such as mid-sized offices, schools, and retail spaces where fewer people are on the network at the same time. With 1.49 Gbps maximum combined data rate, the 500 Series delivers reliable Wi-Fi for medium density environments and is supported by HPE Aruba Networking Central, AI-powered management that simplifies and improves IT operations across branch, remote office, campus, data center, and IoT networks with a single point of visibility and control. The 500 Series is Wi-Fi CERTIFIED™ and supports Wi-Fi 6 (802.11ax) features: OFDMA for multi-user efficiency, target wake time (TWT) to extend the battery life of connected IoT devices, and WPA3 and Enhanced Open for greater password and guest security. The 500 Series includes a limited lifetime warranty.
What is new supporting point:
Dynamic Segmentation and policy enforcement firewalls automatically enforce consistent policies across wired and wireless networks, enhancing user and device security.
Entry level Wi-Fi 6 access points provide up to 1.49 Gbps maximum combined data rate.
Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
IoT-ready with built-in [1] Bluetooth 5 and Zigbee support.
Built-in technology that resolves sticky client issues and improves performance of mobile Wi-Fi clients.
Available in optional eco-friendly 10-packs.
What is new supporting point:
Dynamic Segmentation and policy enforcement firewalls automatically enforce consistent policies across wired and wireless networks, enhancing user and device security.
Entry level Wi-Fi 6 access points provide up to 1.49 Gbps maximum combined data rate.
Support for OFDMA for enhanced multi-user efficiency, and WPA3 and Enhanced Open for greater security.
IoT-ready with built-in [1] Bluetooth 5 and Zigbee support.
Built-in technology that resolves sticky client issues and improves performance of mobile Wi-Fi clients.
Available in optional eco-friendly 10-packs.
Extra Information
Brand:
HPE
Antenna direction type:
Omni-directional
Antenna features:
Integrated antenna
Antennas quantity:
2.0
Compliance certificates:
Low Voltage Directive (LVD)
Certification:
None
Placement:
Ceiling, Wall
Cable lock slot type:
Kensington
Cable lock slot:
Yes
Product colour:
White
Maximum data transfer rate:
1774 Mbit/s
2.4 GHz:
Yes
5 GHz:
Yes
Maximum data transfer rate (2.4 GHz):
574 Mbit/s
Maximum data transfer rate (5 GHz):
1200 Mbit/s
Auto MDI/MDI-X:
Yes
MIMO:
Yes
Spread spectrum method:
DSSS, OFDM, OFDMA
Modulation:
16-QAM, 64-QAM, 256-QAM, 1024-QAM, BPSK, CCK, QPSK
MIMO type:
Multi User MIMO
Harmonized System (HS) code:
85176990.0
Ethernet LAN data rates:
10,100,1000 Mbit/s
Networking standards:
IEEE 802.11ax
Operating temperature (T-T):
0 - 50 °C
Storage temperature (T-T):
-40 - 70 °C
Operating relative humidity (H-H):
5 - 93%
Storage relative humidity (H-H):
5 - 93%
Ethernet LAN (RJ-45) ports:
1.0
USB connector type:
USB Type-A
USB 2.0 ports quantity:
1.0
Power over Ethernet (PoE):
Yes
Power consumption (max):
16.5 W
Security algorithms:
WPA3, WPA, WPA2
Width:
160 mm
Depth:
161 mm
Height:
37 mm
Weight:
500 g
