Ruijie Networks RG-CS86-24XMG4XS4VS-UPD network switch Managed 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) Grey

No reviews yet Write a Review
SKU:
RG-CS86-24XMG4XS4VS-UPD
Ruijie Networks RG-CS86-24XMG4XS4VS-UPD network switch Managed 10G Ethernet (100/1000/10000) Power over Ethernet (PoE) Grey

Description

RG-CS86-24XMG4XS4VS-UPD, 10GE Multi-rate Access Switch
24 x service ports: 10 Gbps/5 Gbps/2.5 Gbps/1 Gbps/100 Mbps access, 4 x 10GE SFP+ ports and 4 x 25GE SFP28 ports for uplink, enabling flexible networking High-power PoE++, offering up to 90 W output and adapting to services in Wi-Fi 6E and Wi-Fi 7 eras

Hardware Redundancy, Guaranteed Service Continuity and Network Connectivity
Hardware-Level Boot Redundancy
Two Flash chips are used to store the system Boot program for hardware-level Boot redundancy, avoiding device failure caused by a failed Flash chip.

VSU Virtualization, Flexible Networking and High Performance
Millisecond Failover
Connected by an aggregate link, the VSU virtual system and peripherals switch links in milliseconds to ensure service continuity in case of a failure.

Network Security Policies and Real-Time Monitoring, Delivering Enhanced Network Robustness
CPP protects the CPU from data attacks to ensure CPU stability under high usage, achieving significant improvement in the device's security performance.

Intelligent Speed Regulation and Auto Sleeping, Reducing Energy Consumption and Noise
Intelligent fan speed regulation based on monitored component temperatures, saving energy, Auto service port sleeping, reducing device power consumption

Key Features

  • Managed Web-based management
  • Basic switching RJ-45 Ethernet ports quantity: 24
  • 10G support
  • MAC address table: 32768 entries Switching capacity: 760 Gbit/s
  • Access Control List (ACL)
  • Rack mounting
  • AC/DC/PoE Power over Ethernet (PoE)

Specifications

Dimensions Weight
Width442 mm
Weight6110 g
Battery
Power protection featuresSurgeprotection
Product colourGrey
Call management
Web-based managementYes
Camera
Built-in processorYes
Processor frequency1250
Computer system
Internal memory1000
Cooling
Number of fans3
Data transmission
Switching capacity760
Design
Operating relative humidity (H-H)10 - 90
Rack mountingYes
Storage relative humidity (H-H)5 - 95
Ethernet LAN features
Ethernet LAN data rates100, 1000 Mbit/s, 2500, 5000, 10000
Features
AC input voltage90 - 264
Depth220
Flash memory1000
Height43
IPv4 multicast entries4000
IPv6 multicast entries2000
ManualYes
Package depth563
Package height210
Package weight8120
Package width563
Power over Ethernet (PoE)Yes
Security algorithmsHTTPS, SNMP, SNMPv2, SNMPv3, SSH, Ssh 2
Switch typeManaged
Virtual LAN featuresIP subnet–based VLAN, MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
VLAN supportYes
Network
10G supportYes
Networking standardsIEEE 802.1Q, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Packaging content
Rack mount kitYes
Performance
Routing protocolsBGP4, Bgp4, Is Is, Ospfv2, Ospfv3, Rip, Ripng
Ports & interfaces
Basic switching RJ-45 Ethernet ports quantity24
Basic switching RJ-45 Ethernet ports type10gethernet 100 1000 10000
Security
DHCP featuresDHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 snooping
IP-MAC-Port bindingYes

Extra Information

Brand:
Ruijie Networks
Width:
442 mm
Weight:
6110 g
Power protection features:
Surgeprotection
Product colour:
Grey
Web-based management:
Yes
Built-in processor:
Yes
Processor frequency:
1250
Internal memory:
1000
Number of fans:
3
Switching capacity:
760
Operating relative humidity (H-H):
10 - 90
Rack mounting:
Yes
Storage relative humidity (H-H):
5 - 95
Ethernet LAN data rates:
100, 1000 Mbit/s, 2500, 5000, 10000
AC input voltage:
90 - 264
Depth:
220
Flash memory:
1000
Height:
43
IPv4 multicast entries:
4000
IPv6 multicast entries:
2000
Manual:
Yes
Package depth:
563
Package height:
210
Package weight:
8120
Package width:
563
Power over Ethernet (PoE):
Yes
Security algorithms:
HTTPS, SNMP, SNMPv2, SNMPv3, SSH, Ssh 2
Switch type:
Managed
Virtual LAN features:
IP subnet–based VLAN, MAC address-based VLAN, Port-based VLAN, Private VLAN, Protocol-based VLAN, Voice VLAN
VLAN support:
Yes
10G support:
Yes
Networking standards:
IEEE 802.1Q, IEEE 802.3ad, IEEE 802.3af, IEEE 802.3at, IEEE 802.3bt
Rack mount kit:
Yes
Routing protocols:
BGP4, Bgp4, Is Is, Ospfv2, Ospfv3, Rip, Ripng
Basic switching RJ-45 Ethernet ports quantity:
24
Basic switching RJ-45 Ethernet ports type:
10gethernet 100 1000 10000
DHCP features:
DHCP client, DHCP relay, DHCP server, DHCP snooping, DHCPv6 client, DHCPv6 relay, DHCPv6 snooping
IP-MAC-Port binding:
Yes
Download | Product Brochure:
https://inishop.com/objects/mmo_118150338_1703680154_5819_13997.pdf
Download | User manual:
https://inishop.com/objects/mmo_118150338_1703680163_121_8183.pdf
