  • Reyee Wi-Fi 7 BE5040 Dual-Band Ceiling Access Point 1x 2.5GB Port

Reyee Wi-Fi 7 BE5040 Dual-Band Ceiling Access Point 1x 2.5GB Port

No reviews yet Write a Review
SKU:
RG-RAP72PRO
Reyee Wi-Fi 7 BE5040 Dual-Band Ceiling Access Point 1x 2.5GB Port

Description

Highlight Features

  • Next-generation performance with Wi-Fi 7, delivering extra-high wireless speeds

  • Superior streaming with Wi-Fi 7's exclusive MLO feature

  • Compact design and easy installation

  • Enhanced data transmission with 4K-QAM for faster speeds

  • Ideal for integrating with enterprise switches to create a robust office network

5 GHz Wi-Fi Protocols

Wi-Fi4: IEEE 802.11a/n
Wi-Fi5: IEEE 802.11ac Wave2
Wi-Fi6: IEEE 802.11ax
Wi-Fi7: IEEE 802.11be

2.4 GHz Wi-Fi Protocols

Wi-Fi4: IEEE 802.11b/g/n
Wi-Fi6: IEEE 802.11ax
Wi-Fi7: IEEE 802.11be

5 GHz Spatial Streams

3 spatial streams, 3x3 MIMO

2.4 GHz Spatial Streams

2 spatial streams, 2x2 MIMO

Wireless Data Rates

5011Mbps

Dimensions (excluding mounting kits)

208 mm x 208 mm x 40 mm (8.19 in. x 8.19 in. x 1.57 in.)

Weight (excluding mounting kits)

≤ 0.65 kg (1.43 lbs.)

Number of 10/100/1000BASE-T Ports

1

Number of 10/100/1000/2500BASE-T Ports

1

Power Supply

802.3at PoE, 12V/2.5A DC

Power Consumption

< 30W

Operating Temperature

0°C to +40°C (32°F to +104°F)

IP Rating

IP41

Max/Recommended Clients

511/110

Certification

CE, RoHS, FCC, ISED, cTUVus

Extra Information

Brand:
Reyee Networks
Antenna direction type:
Omni-directional
Compliance certificates:
CE, Federal Communications Commission (FCC), ISED, RoHS, cTUVus
Product colour:
White
Placement:
Ceiling, Wall
International Protection (IP) code:
IP41
Reset button:
Yes
LED indicators:
System
Internal memory:
512 MB
2.4 GHz:
Yes
5 GHz:
Yes
Maximum data transfer rate (2.4 GHz):
688 Mbit/s
Maximum data transfer rate (5 GHz):
4323 Mbit/s
MIMO type:
Multi User MIMO
Number of users:
511 user(s)
Spread spectrum method:
OFDMA
Receiver sensitivity:
11b: -91dBm(1Mbps)，-88dBm(5.5Mbps)，-\n85dBm(11Mbps)\n11a/g: -89dBm(6Mbps)，-80dBm(24Mbps)，-\n76dBm(36Mbps)，-71dBm(54Mbps)\n11n: -83dBm(MCS0)，-65dBm(MCS7)，-\n83dBm(MCS8)，-65dBm(MCS15)\n11ac: 20MHz: -83dBm(MCS0), -57dBm(MCS9)\n11ac: 40MHz: -79dBm(MCS0),
Wi-Fi Multimedia (WMM)/(WME):
Yes
Antenna type:
Internal
Networking standards:
IEEE 802.11a, IEEE 802.11ac, IEEE 802.11ax, IEEE 802.11b, IEEE 802.11be, IEEE 802.11g, IEEE 802.11k, IEEE 802.11n, IEEE 802.11r, IEEE 802.1x, IEEE 802.3af, IEEE 802.3at
Ethernet LAN data rates:
10,100,1000,2500 Mbit/s
MIMO:
Yes
Operating temperature (T-T):
0 - 40 °C
Storage temperature (T-T):
-40 - 70 °C
Operating relative humidity (H-H):
5 - 95%
Storage relative humidity (H-H):
5 - 95%
Quantity per pack:
1 pc(s)
Maximum data transfer rate:
5011 Mbit/s
Flash memory:
256 MB
Ethernet LAN (RJ-45) ports:
1.0
Power over Ethernet (PoE):
Yes
Input current:
2.5 A
Power consumption (max):
30 W
DC-in jack:
Yes
DC voltage range:
12 V
DHCP server:
Yes
Security algorithms:
OWE, WPA-PSK, WPA-TKIP, WPA2-AES, WPA2-PSK, WPA3-SAE
Number of SSID supported:
8.0
Width:
208 mm
Height:
40 mm
Weight:
650 g
Depth:
208 mm
