Extra Information
Brand:
INTEL
ECC:
Yes
Market segment:
Desktop
Use conditions:
Workstation, PC/Client/Tablet
Maximum number of PCI Express lanes:
20.0
Supported instruction sets:
AVX 2.0, SSE4.1, SSE4.2
Scalability:
1S
Export Control Classification Number (ECCN):
5A992C
Commodity Classification Automated Tracking System (CCATS):
740.17B1
Thermal Monitoring Technologies:
Yes
PCI Express configurations:
1x16+1x4, 2x8+1x4
Thermal solution specification:
PCG 2020A
Direct Media Interface (DMI) Revision:
4.0
On-board graphics card:
Yes
Discrete graphics card:
No
Discrete graphics card model:
Not available
On-board graphics card model:
Intel UHD Graphics 770
On-board graphics card base frequency:
300 MHz
On-board graphics card outputs supported:
Embedded DisplayPort (eDP) 1.4b, DisplayPort 1.4a, HDMI 2.1
On-board graphics card dynamic frequency (max):
1550 MHz
Number of displays supported (on-board graphics):
4.0
On-board graphics card DirectX version:
12.0
On-board graphics card OpenGL version:
4.5
On-board graphics card maximum resolution (DisplayPort):
7680 x 4320 pixels
On-board graphics card maximum resolution (eDP - Integrated Flat Panel):
5120 x 3200 pixels
On-board graphics card maximum resolution (HDMI):
4096 x 2160 pixels
On-board graphics card refresh rate at maximum resolution (DisplayPort):
60 Hz
On-board graphics card refresh rate at maximum resolution (eDP - Integrated Flat Panel):
120 Hz
On-board graphics card refresh rate at maximum resolution (HDMI):
60 Hz
On-board graphics card ID:
0xA780
Number of execution units:
32.0
Multi-Format Codec Engines:
2.0
Harmonized System (HS) code:
8542310001.0
Non-ECC:
Yes
Maximum internal memory:
192 GB
Memory channels:
Dual-channel
Maximum internal memory supported by processor:
192 GB
Memory types supported by processor:
DDR4-SDRAM, DDR5-SDRAM
Memory bandwidth (max):
89.6 GB/s
Tjunction:
100 °C
L2 cache:
20480 KB
Package type:
Box
PCI Express slots version:
4.0, 5.0
Processor family:
Intel® Core™ i5
Processor manufacturer:
Intel
Processor model:
i5-14600K
Processor generation:
Intel® Core™ i5 (14th gen)
Processor cores:
14.0
Processor threads:
20.0
Processor boost frequency:
5.3 GHz
Performance cores:
6.0
Efficient cores:
8.0
Performance-core base frequency:
3.5 GHz
Efficient-core base frequency:
2.6 GHz
Processor cache:
24 MB
Processor cache type:
Smart Cache
Processor base power:
125 W
Maximum turbo power:
181 W
Processor socket:
LGA 1700
Processor operating modes:
64-bit
Processor codename:
Raptor Lake
Processor ARK ID:
236799.0
Cooler included:
No
Stepping:
B0
Efficient-core boost frequency:
4 GHz
Performance-core boost frequency:
5.3 GHz
Maximum number of DMI lanes:
8.0
Memory bandwidth supported by processor (max):
89.6 GB/s
CPU configuration (max):
1.0
Intel 64:
Yes
Enhanced Intel SpeedStep Technology:
Yes
Intel VT-x with Extended Page Tables (EPT):
Yes
Idle States:
Yes
Execute Disable Bit:
Yes
Intel Virtualization Technology for Directed I/O (VT-d):
Yes
Intel Virtualization Technology (VT-x):
Yes
Embedded options available:
No
Intel® Hyper Threading Technology (Intel® HT Technology):
Yes
Intel® Turbo Boost Technology:
2
Intel® AES New Instructions (Intel® AES-NI):
Yes
Intel® Speed Shift Technology:
Yes
Intel® Control-flow Enforcement Technology (CET):
Yes
Intel® OS Guard:
Yes
Intel® Boot Guard:
Yes
Intel® Deep Learning Boost (Intel® DL Boost) on CPU:
Yes
Intel® Volume Management Device (VMD):
Yes
Mode-based Execute Control (MBE):
Yes
Intel® Quick Sync Video Technology:
Yes
Intel® Clear Video HD Technology (Intel® CVT HD):
Yes
Intel® Gaussian & Neural Accelerator (Intel® GNA) 3.0:
Yes
Intel® Thread Director:
Yes
Intel® Secure Key:
Yes
Intel® Standard Manageability (ISM):
Yes
OpenCL version:
3.0
Processor package size:
45 x 37.5 mm
Graphics output:
eDP 1.4b, DP 1.4a, HDMI 2.1
Launch date:
Q4'23
Status:
Launched
