Extra Information
Brand:
HPE
MAC address table:
212992 entries
Switching capacity:
1760 Gbit/s
Throughput:
2000 Mpps
Jumbo frames support:
Yes
Packet buffer memory:
32 MB
Product colour:
Black
Rack mounting:
Yes
Form factor:
1U
Number of fans:
3 fan(s)
Airflow direction:
Back-to-front airflow
Redundant fans support:
Yes
Internal memory:
16384 MB
VLAN support:
Yes
Quality of Service (QoS) support:
Yes
Harmonized System (HS) code:
85176990
Switch type:
Managed
Switch layer:
L3
Multicast support:
Yes
Networking standards:
IEEE 802.1AE, IEEE 802.1AX, IEEE 802.1Q, IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3an, IEEE 802.3ba, IEEE 802.3by, IEEE 802.3cc, IEEE 802.3x, IEEE 802.3z
10G support:
Yes
Ethernet LAN data rates:
100,1000,10000,40000,100000 Mbit/s
Port mirroring:
Yes
Link aggregation:
Yes
Spanning tree protocol:
Yes
Number of VLANs:
4094.0
Operating temperature (T-T):
0 - 45 °C
Operating relative humidity (H-H):
15 - 95%
Storage temperature (T-T):
-40 - 70 °C
Storage relative humidity (H-H):
15 - 95%
Built-in processor:
Yes
Flash memory:
32768 MB
Basic switching RJ-45 Ethernet ports quantity:
48.0
Basic switching RJ-45 Ethernet ports type:
10G Ethernet (100/1000/10000)
Console port:
RJ-45
QSFP+ module slots quantity:
4.0
AC input voltage:
100 - 240 V
Redundant power supply (RPS) support:
Yes
Power source:
AC
Power supply included:
Yes
AC input frequency:
50 - 60 Hz
Power consumption (max):
550 W
Number of power supply units:
2.0
Power over Ethernet (PoE):
No
Processor frequency:
1800 MHz
Management protocols:
SNMP 2, SNMP 3, RMON, TFTP, SSH, SSH-2, CLI, SFTP, NTP, ICMP, IPv4, IPv6, RSTP
Access Control List (ACL):
Yes
IGMP snooping:
Yes
Authentication type:
RADIUS
DHCP features:
DHCP client, DHCP server
SSH/SSL support:
Yes
Width:
442.5 mm
Depth:
406.4 mm
Height:
44 mm
Weight:
8.55 kg
