Description
DELL UltraSharp U3225QE. Display diagonal: 80 cm (31.5"), Display resolution: 3840 x 2160 pixels, HD type: 4K Ultra HD, Display technology: LCD, Response time: 8 ms, Native aspect ratio: 16:9, Viewing angle, horizontal: 178°, Viewing angle, vertical: 178°. Built-in USB hub, USB hub version: 3.2 Gen 2 (3.1 Gen 2). VESA mounting, Height adjustment. Product colour: Black, Silver
Key Features
- 80 cm (31.5") Black, Silver
- Height adjustment 15 cm
- USB upstream port type: USB Type-C HDMI DisplayPorts quantity: 1 DisplayPort version: 1.4
- Screen shape: Flat
- Maximum refresh rate: 120 Hz Response time: 8 ms Response time measurement type: GTG (Gray to Gray)
- 3840 x 2160 pixels 4K Ultra HD Panel type: IPS
- Energy efficiency class (SDR): F ENERGY STAR, TCO RoHS
Specifications
| Dimensions Weight | |
|---|---|
| Weight (without stand) | 6520 g |
| Width (with stand) | 713.2 mm |
| Display Screen | |
| Screen Diagonal (cm) | 800 mm |
| Screen HD Type | 4kultrahd |
| Screen HDR Support | Y |
| Screen LED Backlight Type | Edgeled |
| Screen Native Aspect Ratio | 16 9 |
| Screen Panel Type | IPS |
| Screen Pixel Density (PPI) | 140 |
| Screen Pixel Pitch | 0.18159 x 0.18159 |
| Screen Response Time (ms) | 8 ms |
| Screen Shape | Flatscreen |
| Swiveling Support | Yes |
| Tilt Adjustment Support | Yes |
| VESA Mount Support | Yes |
| Audio | |
| Built-in speaker(s) | No |
| Battery | |
| Product colour | Black, Silver |
| Camera | |
| Built-in camera | No |
| HD type | 4K Ultra HD |
| High Dynamic Range (HDR) supported | Yes |
| On Screen Display (OSD) | Yes |
| Supported graphics resolutions | 1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160, 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA) |
| Tilt angle range | -5 - 21 |
| Carbon footprint | |
| Total carbon footprint (kg of CO2e) | 364 |
| Certificates | |
| Compliance certificates | RoHS |
| Doesn't contain | Arsenic, Mercury, PVC/BFR |
| Computer system | |
| VESA mounting | Yes |
| Design | |
| Cable lock slot | Yes |
| Cable lock slot type | Kensington |
| Cable management | Yes |
| Display diagonal | 31.5 |
| Display resolution | 3840 x 2160 |
| Display technology | LCD |
| Ethernet LAN | Yes |
| Height adjustment | Y |
| LED backlight | Yes |
| Market positioning | Office |
| Operating relative humidity (H-H) | 10 - 80 |
| Operating temperature (T-T) | 0 - 40 |
| Panel mounting interface | 100 x 100 mm |
| Pivot angle | -90 - 90 |
| Storage relative humidity (H-H) | 5 - 90 |
| Storage temperature (T-T) | -20 - 60 |
| Swivel angle range | -30 - 30 |
| Swivelling | Yes |
| Tilt adjustment | Yes |
| Touchscreen | No |
| Wall mountable | Yes |
| Display | |
| Anti-glare screen | Yes |
| Display brightness (peak) | 600 |
| Display brightness (typical) | 450 |
| Low Blue Light technology | Yes |
| Maximum refresh rate | 120 |
| Native aspect ratio | 16:9 |
| Panel type | IPS |
| Pixel density | 140 |
| Response time | 8 |
| sRGB coverage (typical) | 100 |
| Docking station | |
| Built-in USB hub | Yes |
| HDMI ports quantity | 1 |
| USB Power Delivery (USB PD) | Yes |
| USB Power Delivery up to | 120 |
| Ergonomics | |
| Adjustable height (max) | 150 |
| Features | |
| AC input voltage | 100 - 240 |
| Cables included | AC, DisplayPort, Thunderbolt, USB Type-A to USB Type-C |
| Carbon emissions, end-of-life (kg of CO2e) | 27.3 |
| Carbon emissions, energy usage (kg of CO2e) | 150.33 |
| Carbon emissions, logistics (kg of CO2e) | 25.12 |
| Carbon emissions, manufacturing (kg of CO2e) | 161.25 |
| Depth (with stand) | 215 |
| DisplayPort version | 1.4 |
| DisplayPorts quantity | 1 |
| HDMI | Yes |
| Headphone connectivity | 3.5 mm |
| Headphone out | Yes |
| Package weight | 13390 |
| RJ-45 ports quantity | 1 |
| USB Type-C DisplayPort Alternate Mode | Yes |
| Graphics | |
| AMD FreeSync | No |
| NVIDIA G-SYNC | No |
| Performance | |
| Flicker-free technology | Yes |
| Ports & interfaces | |
| DisplayPort out version | 1.4 |
| Weight & dimensions | |
| Height (without stand) | 410.34 |
| Weight (without stand) | 6520 |
| Width (without stand) | 713.2 |
Extra Information
Brand:
DELL
Carbon emissions, manufacturing (kg of CO2e):
161.25
Carbon emissions, logistics (kg of CO2e):
25.12
Carbon emissions, energy usage (kg of CO2e):
150.33
Carbon emissions, end-of-life (kg of CO2e):
27.3
PAIA version:
GaBi version 1, 2024
Cable lock slot:
Yes
Cable lock slot type:
Kensington
Feet colour:
Silver
Market positioning:
Office
Front bezel colour:
Black
Detachable stand:
Yes
Touchscreen:
No
Display diagonal:
31.5
Display resolution:
3840 x 2160
Native aspect ratio:
16:9
HD type:
4K Ultra HD
Panel type:
IPS
Screen Shape:
Flatscreen
Contrast ratio (typical):
3000:1
Maximum refresh rate:
120
Display number of colours:
1.07 billion colours
Display brightness (typical):
450
Supported graphics resolutions:
1024 x 768 (XGA), 1152 x 864 (XGA+), 1280 x 1024 (SXGA), 1280 x 800 (WXGA), 1600 x 1200 (UXGA), 1680 x 1050 (WSXGA+), 1920 x 1080 (HD 1080), 1920 x 1200 (WUXGA), 2560 x 1440, 3840 x 2160, 640 x 480 (VGA), 720 x 400, 800 x 600 (SVGA)
Viewing angle, horizontal:
178°
Viewing angle, vertical:
178°
Viewable size, horizontal:
69.7 cm
Viewable size, vertical:
39.2 cm
Display technology:
LCD
Anti-glare screen:
Yes
Pixel pitch:
0.18159 x 0.18159 mm
Digital horizontal frequency:
30 - 275 kHz
Display diagonal (metric):
68.47 cm
Backlight type:
Edge LED
Response time (fast):
5 ms
Pixel density:
140
LED backlight:
Yes
Viewable size diagonal:
80 cm
High Dynamic Range (HDR) supported:
Yes
Surface hardness:
3H
sRGB coverage (typical):
100
High Dynamic Range (HDR) technology:
DisplayHDR 600
Display brightness (peak):
600
Digital vertical frequency:
48 - 120 Hz
Response time measurement type:
GTG (Gray to Gray)
DCI-P3 coverage:
99%
Height adjustment:
Y
Tilt adjustment:
Yes
Tilt angle range:
-5 - 21
Swivelling:
Yes
Swivel angle range:
-30 - 30
VESA mounting:
Yes
Adjustable height (max):
150
Pivot:
Yes
Pivot angle:
-90 - 90
Cable management:
Yes
On Screen Display (OSD):
Yes
Product colour:
Black, Silver
Wall mountable:
Yes
Panel mounting interface:
100 x 100 mm
Built-in speaker(s):
No
Built-in camera:
No
Ethernet LAN:
Yes
Operating temperature (T-T):
0 - 40
Storage temperature (T-T):
-20 - 60
Operating relative humidity (H-H):
10 - 80
Storage relative humidity (H-H):
5 - 90
Operating altitude:
0 - 5000 m
Non-operating altitude:
5000 - 12192 m
RJ-45 ports quantity:
1
Cables included:
AC, DisplayPort, Thunderbolt, USB Type-A to USB Type-C
Stand included:
Yes
DisplayPort cable length:
1.8 m
Package weight:
13390
Supported video modes:
480p, 576p, 720p, 1080p, 2160p
NVIDIA G-SYNC:
No
AMD FreeSync:
No
Flicker-free technology:
Yes
Low Blue Light technology:
Yes
HDMI ports quantity:
1
DisplayPorts quantity:
1
Headphone connectivity:
3.5 mm
Built-in USB hub:
Yes
HDMI:
Yes
Headphone out:
Yes
USB hub version:
3.2 Gen 2 (3.1 Gen 2)
USB Type-A downstream ports quantity:
5.0
DisplayPort version:
1.4
HDCP:
Yes
Thunderbolt 4 ports quantity:
2.0
USB Power Delivery up to:
120
USB Type-C DisplayPort Alternate Mode:
Yes
Number of USB Type-C upstream ports quantity:
1.0
USB upstream port type:
USB Type-C
USB Type-C downstream ports quantity:
2.0
HDCP version:
2.2
DisplayPort out quantity:
1.0
DisplayPort out version:
1.4
AC input voltage:
100 - 240
AC input frequency:
50/60 Hz
Power consumption (max):
335 W
Power consumption (typical):
30.5 W
Input current:
4 A
USB Power Delivery (USB PD):
Yes
Energy efficiency class (SDR):
F
Energy consumption (SDR) per 1000 hours:
31 kWh
Power consumption (standby):
0.5 W
Power consumption (off):
0.3 W
Energy efficiency scale:
A to G
Energy efficiency class (HDR):
G
Energy consumption (HDR) per 1000 hours:
52 kWh
Response time:
8
Sustainability certificates:
ENERGY STAR, TCO
Doesn't contain:
Arsenic, Mercury, PVC/BFR
Total carbon footprint (kg of CO2e):
364
Compliance certificates:
RoHS
Weight (with stand):
9.02 kg
Width (with stand):
713.2 mm
Depth (with stand):
215
Height (with stand):
618.9 mm
Width (without stand):
713.2
Depth (without stand):
57.5 mm
Height (without stand):
410.34
Weight (without stand):
6520 g
Bezel width (side):
7.95 mm
Bezel width (top):
7.7 mm
Bezel width (bottom):
1.04 cm
Screen Diagonal (cm):
800 mm
Screen HD Type:
4kultrahd
Screen HDR Support:
Y
Screen LED Backlight Type:
Edgeled
Screen Native Aspect Ratio:
16 9
Screen Panel Type:
IPS
Screen Pixel Density (PPI):
140
Screen Pixel Pitch:
0.18159 x 0.18159
Screen Response Time (ms):
8 ms
Swiveling Support:
Yes
Tilt Adjustment Support:
Yes
VESA Mount Support:
Yes
Weight (without stand):
6520
Download | Brochure DELL DELL-U3225QE:
https://icecat.biz/rest/product-pdf
Download | EU Declaration of Conformity:
https://objects.icecat.biz/objects/mmo_129039635_1741189220_5686_49.pdf
Download | EU Energy Label:
https://objects.icecat.biz/objects/mmo_129039635_1741162135_5291_1762539.pdf
Download | Dell UltraSharp 32 4K Thunderbolt Hub Monitor U3225QE User’s Guide:
https://objects.icecat.biz/objects/mmo_129039635_1741189218_0861_57.pdf
Download | Dell products compatible with USB Type-C Power Delivery 3.1 (Extended Power Range 140 W) Tech sheet:
https://objects.icecat.biz/objects/mmo_129039635_1741189237_3153_28.pdf
Download | EU Product Fiche:
https://objects.icecat.biz/objects/mmo_129039635_1741162287_5563_1756962.pdf
Download | Statement of Volatility - Dell UltraSharp 32 4K Thunderbolt Hub Monitor U3225QE:
https://objects.icecat.biz/objects/mmo_129039635_1741189216_1317_49.pdf
Download | Dell UltraSharp 32 4K Thunderbolt Hub Monitor U3225QE Teardown Instruction:
https://objects.icecat.biz/objects/mmo_129039635_1741189236_7136_35.pdf
Download | User manual:
https://objects.icecat.biz/objects/mmo_129039635_1754471774_7891_3966689.pdf
Download | Dell UltraSharp 32 4K Thunderbolt Hub Monitor U3225QE Quick Start Guide:
https://objects.icecat.biz/objects/mmo_129039635_1741189221_5524_45.pdf
ERP Category:
DELL_RETAIL
Icecat Category:
Computer Monitors
