Description
The HPE Aruba Networking CX 6300 Switch Series is a modern, flexible, and intelligent family of stackable switches ideal for access, aggregation, and data center top-of-rack (ToR). Featuring a cloud-native design and fully programmable operating system (OS). The CX 6300 delivers advanced monitoring and troubleshooting with capabilities like a real-time network analytics engine, HPE Aruba Networking Switch Multi-Edit Software and flexible deployment options to implement and validate network configurations. A powerful Gen7 ASIC architecture delivers fast, non-blocking performance for AI, Wi-Fi 7, and Internet of Things (IoT) requirements. HPE Aruba Networking Virtual Stacking Framework (VSF) allows for stacking of up to 10 switches, providing scale and simplified management. This flexible series has built-in high-speed uplinks and supports high-density IEEE 802.3bt high-power PoE with HPE Smart Rate multi-gigabit Ethernet.
What is new supporting point:
The HPE Aruba Networking CX 6300 Switch Series is a family of stackable Layer 3 switches with BGP, EVPN, VXLAN, VRF, OSPF routing, robust quality of service (QoS), MACsec 256, PTP, AVB and LRM [1]
Three stackable Layer 2-only CX 6300L switches with HPE Smart Rate multi-gigabit and MACsec 256 encryption are available for high performance access deployments
Powerful 7th Gen ASIC architecture provides the CX 6300 series with 880 to 1760 Gbps system switching capacity, 660 to 1310 Mpps of system throughput and up to 200 to 400 Gbps stacking bandwidth
High availability with choice between 2 to 10-member Virtual Switching Framework (VSF) stacking for scale, or 2-member Virtual Switching Extension (VSX) cluster for active-active redundancy
Options include 24 to 48-port of HPE Smart Rate multi-gigabit (1/2.5/5/10GbE) and 1GbE fiber, supporting up to 90W 802.11bt PoE, all with telemetry and automation via the CX Network Analytics Engine
Manage through single point of control with HPE Aruba Networking Central across wired, wireless, and WAN. Dynamic segmentation enables enhanced security and simple access for users and IoT
What is new supporting point:
The HPE Aruba Networking CX 6300 Switch Series is a family of stackable Layer 3 switches with BGP, EVPN, VXLAN, VRF, OSPF routing, robust quality of service (QoS), MACsec 256, PTP, AVB and LRM [1]
Three stackable Layer 2-only CX 6300L switches with HPE Smart Rate multi-gigabit and MACsec 256 encryption are available for high performance access deployments
Powerful 7th Gen ASIC architecture provides the CX 6300 series with 880 to 1760 Gbps system switching capacity, 660 to 1310 Mpps of system throughput and up to 200 to 400 Gbps stacking bandwidth
High availability with choice between 2 to 10-member Virtual Switching Framework (VSF) stacking for scale, or 2-member Virtual Switching Extension (VSX) cluster for active-active redundancy
Options include 24 to 48-port of HPE Smart Rate multi-gigabit (1/2.5/5/10GbE) and 1GbE fiber, supporting up to 90W 802.11bt PoE, all with telemetry and automation via the CX Network Analytics Engine
Manage through single point of control with HPE Aruba Networking Central across wired, wireless, and WAN. Dynamic segmentation enables enhanced security and simple access for users and IoT
Key Features
- Managed L3
- Quality of Service (QoS) support Configuring Location Settings (CLI)
- Basic switching RJ-45 Ethernet ports quantity: 24 Console port: USB
- 10G support
- Switching capacity: 448 Gbit/s
- Access Control List (ACL)
- Rack mounting Stackable
- Power supply included
Specifications
| Dimensions Weight | |
|---|---|
| Width | 44 mm |
| Weight | 4360 g |
| Battery | |
| Product colour | Black |
| Camera | |
| Built-in processor | Yes |
| Processor frequency | 1800 |
| Computer system | |
| Internal memory | 8000 |
| Cooling | |
| Noise level | 31 |
| Data transmission | |
| Latency (1 Gbps) | 2 |
| Latency (10 Gbps) | 1 |
| Switching capacity | 448 |
| Design | |
| Operating relative humidity (H-H) | 15 - 95 |
| Rack mounting | Yes |
| Storage relative humidity (H-H) | 15 - 90 |
| Features | |
| AC input voltage | 200 - 240 |
| Depth | 442 |
| Fan | Fixed fans |
| Flash memory | 32000 |
| Harmonized System (HS) code | 85176990 |
| Height | 327 |
| I/O ports | 24 x 10/100/1000 BaseT ports 4 x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at 1 x USB-C console port 1 x USB Type-A host port 1 x OOBM port |
| IPv4 multicast entries | 8000 |
| IPv6 multicast entries | 8000 |
| Power over Ethernet (PoE) | No |
| Quality of Service (QoS) support | Yes |
| SFP+ module slots quantity | 4 |
| Switch layer | L3 |
| Switch type | Managed |
| VLAN support | Yes |
| Network | |
| 10G support | Yes |
| Networking standards | IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3bt |
| Packaging content | |
| Rack mount kit | Yes |
| Performance | |
| Physical stacking (units) | 10 |
| Routing protocols | OSPF, Ospfv3 |
| Ports & interfaces | |
| Basic switching RJ-45 Ethernet ports quantity | 24 |
| Basic switching RJ-45 Ethernet ports type | Gigabitethernet 10 100 1000 |
| Security | |
| DHCP features | DHCP relay, DHCP server |
| SSH/SSL support | Yes |
Extra Information
Brand:
HPE
MAC address table:
64000 entries
Switching capacity:
448
Throughput:
285.7 Mpps
Latency (1 Gbps):
2
Latency (10 Gbps):
1
Jumbo frames support:
Yes
Packet buffer memory:
13.5 MB
Product colour:
Black
Rack mounting:
Yes
Stackable:
Yes
Form factor:
1U
Memory type:
DDR3-SDRAM
Networking standards:
IEEE 802.1ab, IEEE 802.1ak, IEEE 802.1D, IEEE 802.1p, IEEE 802.1s, IEEE 802.1v, IEEE 802.1w, IEEE 802.3ad, IEEE 802.3ae, IEEE 802.3bt
Auto MDI/MDI-X:
Yes
Harmonized System (HS) code:
85176990
Switch type:
Managed
Switch layer:
L3
Quality of Service (QoS) support:
Yes
Web-based management:
Yes
Internal memory:
8000
10G support:
Yes
Link aggregation:
Yes
Spanning tree protocol:
Yes
VLAN support:
Yes
Full duplex:
Yes
Copper ethernet cabling technology:
100BASE-TX, 1000BASE-T
IP routing:
Yes
Operating relative humidity (H-H):
15 - 95
Operating temperature (T-T):
0 - 45 °C
Storage temperature (T-T):
-40 - 70 °C
Storage relative humidity (H-H):
15 - 90
Physical stacking (units):
10
Built-in processor:
Yes
Virtual stacking (units):
10.0
Basic switching RJ-45 Ethernet ports type:
Gigabitethernet 10 100 1000
SFP+ module slots quantity:
4
Console port:
RJ-45
Power over Ethernet (PoE):
No
Power source:
AC
Power supply included:
No
AC input voltage:
200 - 240
AC input frequency:
50 - 60 Hz
Processor frequency:
1800
Access Control List (ACL):
Yes
DHCP features:
DHCP relay, DHCP server
Width:
44 mm
Depth:
442
Height:
327
Weight:
4360 g
Noise level:
31
Fan:
Fixed fans
Flash memory:
32000
I/O ports:
24 x 10/100/1000 BaseT ports 4 x 1G/10G/25G/50G [4] SFP ports Supports PoE standards IEEE 802.3af, 802.3at 1 x USB-C console port 1 x USB Type-A host port 1 x OOBM port
IPv4 multicast entries:
8000
IPv6 multicast entries:
8000
Rack mount kit:
Yes
Routing protocols:
OSPF, Ospfv3
Basic switching RJ-45 Ethernet ports quantity:
24
SSH/SSL support:
Yes
